WaveDump
CAEN Digitizer readout application
Features
- Basic console for waveforms acquisition
- Multichannel waveform plot
- Advanced mode configuration:
- common board settings
- individual settings for threshold and DC offset adjustment
- 725-730-751 ADC calibration
- Advanced mathematical functions: amplitude spectra and FFT
- Configuration of 742 boards and DRS4 chip corrections
- Family-specific function setting (e.g. Decimation for 724 and 740 boards)
- Multi format (ASCII, binary) data saving
- Source files and Visual Studio project open source for developer
Overview
WaveDump is a basic console application supporting digitizers running Waveform Recording firmware. WaveDump allows the user to program a single board (according to a text configuration file containing a list of parameters and instructions), to start/stop the acquisition. It is then possible to read the data, display the readout and trigger rate. Moreover, it is possible to apply some post-processing (e.g. FFT and amplitude histogram), save data into a file and also plot the waveforms using Gnuplot third-party graphical utility (www.gnuplot.info).
WaveDump is a very helpful example of C code demonstrating the use of libraries and methods for an efficient readout and data analysis. Expert users can start with this demo to write their own acquisition software to exploit the full potentialities of the digitizers. Source files and the VS project are available for free download.
NOTE: WaveDump does not support DPP firmware.
Supported Operating Systems: | Windows, Linux |
Language: | C |
Supported Products: | VME, NIM and Desktop Digitizers |
Supported Comm. Interface: | USB, Optical Link, Ethernet, VME |
Additional Software Required: | CAENDigitizer, CAENComm, CAENVMELib, Gnuplot (Linux only) |
Applications
- Signal inspection and waveform recording
- Research and development of prototypes
- Data collection for offline statistical analysis
- Beam monitoring
- Sensors readout and detectors’ performances
- Lida
