8 Channel 6 kV/ 1 mA NIM Power Supply Module (USB/Ethernet/Touchscreen)


  • 2U NIM module
  • 6 kV / 1 mA output ranges
  • Channels with either positive or negative polarity
  • SHV coaxial output connectors
  • Low Ripple
  • 20 mV Vset resolution
  • 5 nA Iset resolution
  • Under/over-voltage alert, overcurrent and max. voltage protection
  • Programmable ramp-up / ramp-down (1-500 V/s)
  • Daisy-chain capabilty
  • 2.8″ color touch screen display
  • Local and Remote control (USB2.0/Ethernet)
  • Interlock logic for board enable and Individual channel kill
  • Software Tool for easy channel management


The Mod. N8034 provides 8 independent 6 kV/ 1 mA channels in a double width NIM mechanics. Each channel can provide a 6 kV max voltage and a 1 mA max current. The unit is available with positive, negative and “mixed” (4 positive and 4 negative) channels.

Channels outputs are delivered through SHV connectors. The HV output RAMP-UP and RAMP-DOWN rates may be selected independently for each channel in the range 1÷500 V/s in 1 V/s steps. The module features 5 nA Iset resolution.

Module control can take place either locally thanks to a 2.8″ Touchscreen Graphic color LCD display with a completely redesigned user interface or remotely, via USB 2.0 or Ethernet.

A complete set of Software Tools is available to control these units; the user can freely download low level libraries, LabVIEW driver and Graphical application software. Moreover a built-in web interface (Coming Soon) is available to easily controls the module with no need to install software on a PC. The user can monitor the status of the module and configure the HV parameters for each channel in real time.


Safety features include:

  • OVERVOLTAGE and UNDERVOLTAGE warning when the output voltage differs from the programmed value by more than 2% of set value (minimum 10V).
  • Programmable VMAX protection limit
  • OVERCURRENT detection: if a channel tries to draw a current larger than its programmed limit, it enters TRIP status, keeping the maximum allowed value for a programmable time (TRIP), before being switched off
  • Common Interlock logic for channels enable/disable and individual inputs signal for channel Kill function.

Technical Specifications

Output ranges

6 kV / 1 mA

Output channels

8 channels, SHV connector
Positive, Negative or Mixed (4 positive and 4 negative) Polarity

Max. Ch. Output Power

6 W

Vset / Vmon Resolution


Iset Resolution

5 nA

Imon Resolution

5 nA (high range) / 500 pA (low range)


0 ÷ 6 kV

Vmax resolution

1 V

Ramp Up/Down

1÷500 Volt/s, 1 Volt/s step

Voltage Ripple

10 – 1000Hz: <15mV typ; <20mV max.
>1kHz: <5mV typ; <10mV max

Vmon vs. Vout Accuracy

± 0.02% ± 1V

Vset vs. Vout Accuracy

± 0.02% ± 1V

Imon vs. Iout Accuracy

± 0.2% ± 1µA

Iset vs. Iout Accuracy

± 0.2% ± 1µA

Humidity range

0 ÷ 80%

Operating temperature

0 ÷ 45°C

Storage temperature

-10 ÷ 70°C

Vout / Temperature coefficient

100 ppm / °C

Long Term stability (24h after 1h warmup)

±0,02% constant temp, Vout = 3kV, no load

Local Control

LCD touchscreen

Remote Control

USB & Ethernet


Double width NIM mechanics. Weight: ~2.6 kg


Compare with NIM High Voltage Power Supplies.


Ordering Options

Code Description
WN8034XAAAAA N8034N - 8 Channel NIM Programmable High Voltage Power Supply (-6KV 1mA) - SHV Common Gnd
WN8034XMAAAA N8034M - 8 Channel NIM Programmable High Voltage Power Supply (4ch-6KV 1mA, 4ch+6KV 1mA) - SHV
WN8034XPAAAA N8034P - 8 Channel NIM Programmable High Voltage Power Supply (+6KV 1mA) - SHV Common Gnd
