A385

16 Channel Flat-to-LEMO Cable Adapter for V785

Overview

The Mod. A385 allows to provide the V785 ADC with LEMO 00 input connectors, when inserted into the Header connectors. The model A385 fits into one 17+17-pin, male Header-type connector and is provided with 16 LEMO 00 female connectors. It can also be used to match the output flat connectors of the N568 B/LC Spectroscopy Amplifiers with the LEMO input connectors of a discriminator (such as V812, V895, C808, N844 etc.). The devices are completely passive mechanical adapters for analog signals and feature 50 cm ±10% long cables.
Mod. A385M with 1 m ±10% long cables is also available.

Ordering Options

Code Description
WA385XAAAAAA A385 - 16 Channel Cable Adapter (Flat to Lemo) forV785, 50cm ±10% cables
WA385XMAAAAA A385M - 16 Channel Cable Adapter (Flat to Lemo)for V785, 1m ±10% cables
WA385MCXAAAA A385MCX - 16 Channel Cable Adapter (Flat to MCX) for V785, 50cm ±10% cables
WA385MCXMAAA A385MCXM - 16 Channel Cable Adapter (Flat to MCX) for V785, 1m ±10% cables
7A385MCXAAAA A385MCX - 16 Channel Cable Adapter (Flat to MCX) for V785, 50cm ±10% cables
