DPP-SUP

New

Super Licence for x725

  • DPP-SUP Licence is valid for all DPP Firmware available for 725 and 730 digitizer families
  • Algorithms for Digital Pulse Processing licensed:

Overview

DPP-SUP Super Licence:

  • DPP-SUP Licence is valid for all DPP Firmware available for a single Digitizer
  • The licence registration procedure is automatic and can be completed on our web site



Different Digital Pulse Processing firmware be available for those CAEN digitizers which support them. These DPPs are freely downloadable in a “trial” version, complete in terms of functionalities but operating only for 30 minutes per board power cycle.
If you want to unlock the firmware, you need to buy a license by sending to CAEN a formal purchase request specifying the product code of the DPP you want to unlock.
The licence registration procedure is automatic and can be completed on our web site. At the end of the registration process, a Product Unlock_Code (PUC) is provided to you. You can use it with CAENUpgrader software to unlock the firmware on your digitizer.
CAEN DPP-SUP is a licence valid for all DPP Firmware available for 725 and 730 digitzer families; in this way the digitizer is unlocked for all the DPP firmware available for it.
The firmware supported by this license are:

psd
Digital Pulse Height Analysis
Pulse Height Analysis for gamma ray spectroscopy applies to voltage signals coming from HPGe/Si detectors and Scintillators coupled with Charge Sensitive Preamplifiers. Works with independent channels event acquisition and in time stamped list mode. Energy spectra are built by the supported software like the new CoMPASS and MC2 Analyzer.
psd
Pulse Shape Discrimination
Pulse Shape Discrimination for gated charge integration and gamma-neutron discrimination is suited for current signals coming from Scintillators, Gas tubes, SiPM and PMT. Works with independent channels event acquisition and in energy & timing list mode. Features digital CFD and timing interpolation for high resolution time information, as well as pulse shape discrimination. Energy spectra are built by the supported software like the new CoMPASS and the DPP-PSD Control Software.
psd
Zero Length Encoding
Zero Length Encoding for advanced zero suppression works with a common trigger and simultaneous acquisition on all channels. The digitized waveforms are transferred in compressed mode by suppressing baseline and empty channels.
psd
Dynamic Acquisition Window
Dynamic Acquisition Window is suited for zero suppression with trigger-less acquisition systems. Works in waveform mode and independent channels event acquisition dynamically stretching the acquisition window (record length) to fit the actual input pulse duration.

Ordering Options

Code Description
WFWDPPS2501A DPP-SUP - Super Licence for 16ch x 725 Digital Pulse Processing
WFWDPPS2505A DPP-SUP - Super Licence for x725 Digital Pulse Processing - 5 Licence Pack (Obsolete)
WFWDPPS2510A DPP-SUP - Super Licence for x725 Digital Pulse Processing - 10 Licence Pack (Obsolete)
WFWDPPS2520A DPP-SUP - Super Licence for x725 Digital Pulse Processing - 20 Licence Pack (Obsolete)
WFWDPPS3001A DPP-SUP - Super Licence for 16ch x 730 Digital Pulse Processing
WFWDPPS3005A DPP-SUP - Super Licence for x730 Digital Pulse Processing - 5 Licence Pack (Obsolete)
WFWDPPS3010A DPP-SUP - Super Licence for x730 Digital Pulse Processing - 10 Licence Pack (Obsolete)
WFWDPPS3020A DPP-SUP - Super Licence for x730 Digital Pulse Processing - 20 Licence Pack (Obsolete)
WFWDPPS2501D DPP-SUP - Super Licence for 8ch x 725 Digital Pulse Processing
WFWDPPS3001D DPP-SUP - Super Licence for 8ch x 730 Digital Pulse Processing
